ACHIEVE LOW-LIGHT AERIAL CREATIVITY
Expand your creative horizons by flying with your Sony α7s and α7r. For the first time, capture beautiful footage in low-light environments with the reliability of a DJI 3-axis aerial stabilization gimbal, the Zenmuse Z15-A7.
UNMATCHED ZENMUSE PRECISION AND STABILITY
Zenmuse gimbals are trusted by professional filmmakers and photographers around the world because of their stability, precision, and reliability. We pour all of our experience in aerial filmmaking into every gimbal, giving you perfect stability in any flight conditions.
Engineered and balanced specifically for the Sony α7s and α7r, this lightweight system works with your current tools seamlessly. A HDMI-AV/HD video output module enables live streaming and remote shutter control, and you can switch between AV or HDMI output easily.
COMPLETE 360° CONTROL
Experience unhindered camera control at a maximum yaw of ±360°, pitch of +50°/-140°, and a roll of ±40°. With precision control of ±0.01°, you are directing your shots and capturing exactly what you need.
FULLY COMPATIBLE SOLUTION
Fly with a DJI S900 or the S1000+ and an advanced flight controller, such as the A2 or WooKong-M, for a seamless, professional experience. Connect the DJI Lightbridge HD digital video downlink or an iOSD Mark II and a 5.8G video link for even more tools on set.
MULTIPLE CONTROL MODES
Choose the right level of camera maneuverability for every situation. Switching between orientation-locked, non-orientation-locked, and FPV (First Person View) controls is quick and easy.
GIMBAL SERVO DRIVE MODULE
The Gimbal Servo Drive Module dramatically improves the control and stability of the gimbal while maximizing torque and minimizing vibration. The module is able to achieve such perfection because it has been fine-tuned to the weight and balance of the individual camera that the gimbal was built to support.
BUILT-IN INDEPENDENT IMU MODULE AND INFRARED MODULE
A new stabilizing algorithm provides more stability than ever before, and the extremely precise induction devices give you effortless attitude control. Because the IMU is built in, your gimbal requires no extra equipment or wiring, reducing its overall weight and allowing you to start shooting in no time at all. By attaching an infrared receiver, remote shutter control capability can be added to the Z15-A7 gimbal system, letting you command the camera during flight.
Sony ILCE-7S; Sony ILCE-7R
Sony FE 35 mm f2.8 ZA
GCU Input Power
4S~12S LiPo (Recommend 6S if with S1000+)
At least four spare receiver channels
Assistant Software System Requirements
Windows XP SP3; Windows 7; Windows 8 (32 or 64 bit)
Mechanical& Electrical Characteristics
Static current: 200 mA (@25 V)
Dynamic current: 400 mA (@25 V)
Locked-motor current: 4 A (@25 V)
-10°C ~ 50°C
64.2 mm ×34.1mm ×19.5mm
Load Weight (Reference Value)
622 g(@Sony ILCE-7S with Sony FE 35 mm f2.8 ZA, battery, lens hood and SD Card)
580 g(@Sony ILCE-7R with Sony FE 35 mm f2.8 ZA, battery, lens hood and SD Card)
Angular Vibration Range
Maximum Controlled Rotation Speed
Pan axis: ±130°/s
Tilt axis: ±130°/s
Roll axis: ±30°/s
Controlled Rotation Range
Pan axis control: ±360° continuous rotation
Tilt axis control: +50°/-140°
Roll axis control: ±40°
