DJI Transmission perdavimo sistema

Weight
Video Transmitter Weight: Approx. 350 g / 0.77 lbs (excluding antennas)
High-Bright Remote Monitor Weight: Approx. 727 g / 1.6 lbs (excluding antennas)

Dimensions
Video Transmitter: 127×87×26 mm (L×W×H, excluding antennas)
High-Bright Remote Monitor: 213×135×51 mm (L×W×H, excluding antennas)

Operating Frequency
Non DFS Frequency Band:
2.4000-2.4835 GHz
5.150-5.250 GHz
5.725-5.850 GHz

DFS Frequency Band:
5.250-5.350 GHz
5.470-5.600 GHz
5.650-5.725 GHz"

Transmitter Power (EIRP)
2.4000-2.4835 GHz:
<33 dBm (FCC)
<20 dBm (SRRC/CE/MIC)

5.150-5.250 GHz:
<23 dBm (FCC/SRRC/MIC)

5.250-5.350 GHz:
<30 dBm (FCC)
<23 dBm (SRRC/MIC)

5.470-5.600 GHz, 5.650-5.725 GHz:
<30 dBm (FCC)
<23 dBm (CE/MIC)

5.725-5.850 GHz:
<33 dBm (FCC/SRRC)
<14 dBm (CE)

Max Bandwidth
40 MHz

Max Bitrate
40 Mbps

Power Consumption
11 W

Power Supply Voltage
6 to 18 V

Output Voltage
Power Output Port: 6 to 18 V

Operating Time
Video Transmitter: 3 hours 40 minutes
High-Bright Remote Monitor: 2 hours

Input Video Format
3G SDI: YCbCr 4:2:2 10-bit
HDMI RGB 4:4:4
1080p: 23.98/24/25/29.97/30/50/59.94/60fps
1080i: 50/59.94/60fps
720p: 50/59.94/60fps

Output Video Format
3G SDI: YCbCr 4:2:2 10-bit
1080p: 23.98/24/25/29.97/30/50/59.94/60fps
1080i: 50/59.94/60fps
720p: 50/59.94/60fps

Input Audio Format
SDI embedded, HDMI embedded

Output Audio Format
PCM

Video Transmission System
O3 Pro

Video Transmission Latency
68 ms

100 ms

Video Coding Format
H.264

Max Transmission Distance
6 km (FCC)
4 km (CE/SRRC/MIC)

-10° to 45° C

Mirror Control Mode Supported Camera Models
ZV1/A7 III/A7S III/A7M III/A7R III/A7R IV/A7 IV/FX3/A7S II/A6600/A6400 and all Sony cameras that support BRAVIA (HDMI control).
