"9 Multi-Rotor Configurations & Customized Motor Mixer"
"The A2 was designed for commercial and industrial multi-rotor platforms. Simple configuration, easy installation, and stable performance make it perfect for almost any application. The A2 also supports customized motor mixing, which allows it to meet the specific demands of individual users.
The A2 supports nine different motor configurations: Quad I / Quad X / Hex I / Hex V / Hex IY / Oct X / Oct I / Oct V"
Intelligent Orientation Control (IOC)
"Usually, the forward flight direction corresponds with the aircraft's nose direction. Intelligent Orientation Control (IOC) allows the forward direction to be set to any specified direction, regardless of how the nose orientation changes during flight.
In Course Lock flying, the forward flight direction is set to correspond with nose direction of the aircraft at the time that Course Lock mode is activated. In Home Lock flying, the forward flight direction is the same as the direction from Home Point to the aircraft."
Point of Interest (POI)
Users can record the position of the aircraft as a Point of Interest, at any time, using a switch on the remote controller. Then, when the left control stick is pushed either left or right, the aircraft can perform a circular flight around the Point of Interest, with its nose pointing toward the POI. This distance from the aircraft to the POI can be set between 16 feet (5 meters) and 1,640 feet (500 meters). This function is easy to set up and simple to operate, making it the ideal solution for when you want to fly 360 degrees around a specific point at a fixed distance.
Intelligent Landing Gear
Once the Intelligent Landing Gear function has been enabled in the Assistant software, the landing gear will be lowered whenever the aircraft is close to the ground. The system will automatically lower the landing gear in the case of an emergency, motor failure, or auto landing event. This serves to protect the aircraft and the gimbal. You can use the switch to manually change the position of the landing gear when the aircraft reaches an altitude of 16 feet (5 meters) or greater.
Auto Return-to-Home
"If the connection between the aircraft and the controller is broken during flight, and the aircraft's GPS signal is strong enough, the aircraft will return to the Home Point and land automatically.
You can also press the Return-to-Home button to manually activate this feature at any time."
"Banked Turn" Mode
In this mode, the roll and yaw control sticks are combined in order to help you perform banked turns using one hand. The aircraft can be maneuvered like a fixed-wing aircraft, thereby providing a new flight experience. Normal and FPV aerial photography are stable and smooth, giving your work a whole new visual effect.
Cruise Control
Activate Cruise Control to lock your aircraft into its current horizontal speed. While cruise control is active, the speed can be adjusted at any time using the remote controller. By maintaining a steady flight speed, you can dedicate more attention to controlling the camera and capture the perfect shot every time. This function also increases the total flight time by eliminating unnecessary speed changes that increase power consumption.
DJI Enterprise
Frame | Diagonal Wheelbase1045mm Frame Arm Length386mm Frame Arm Weight |
---|---|
Motor | Stator Size41×14mm KV400rpm/V Max Power500W Weight(With Cooling Fan)158g |
ESC | Working Current40A Working Voltage6S LiPo Signal Frequency30Hz ~ 450Hz Drive PWM Frequency8KHz Weight(With Radiators)35g |
Foldable Propeller (1552/1552R) | MaterialHigh strength performance engineered plastics Size15×5.2inch Weight13g |
Flight Parameters | Takeoff Weight6.0Kg ~ 11.0Kg Total Weight4.4Kg Power BatteryLiPo (6S,10000mAh~20000mAh,15C(Min)) Max Power Consumption4000W Hover Power Consumption1500W (@9.5Kg Takeoff Weight) Hover Time15min (@15000mAh & 9.5Kg Takeoff Weight) Working Environment Temperature-10 °C ~ +40 °C |
Gain Value Settings | For A2 Flight ControllerBasic: Roll 120%, Pitch 120%, Yaw 120% Attitude: Roll 170%, Pitch 170%, Vertical 120% For WooKong-M Flight ControllerBasic: Roll 130%, Pitch 130%, Yaw 120% Attitude: Roll 180%, Pitch 180%, Vertical 120% |
Size and Weight | ![]() |
---|---|
Peripheral | Supported Multi-RotorQuad-Rotor: +4,x4; Hex-Rotor +6,x6,Y6,Rev Y6; Octo-Rotor +8,x8,V8 Supported ESC Output400Hz refresh frequency Supported Transmitter For Built-In ReceiverFutaba FASST Series and DJI DESST Series External Receiver SupportedFutaba S-Bus, S-Bus2, DSM2 Recommended Battery2S ~ 6S LiPo Operating Temperature-5°C to +60°C Assistant Software System RequirementWindows XP SP3 / 7 /8 (32 or 64 bit) Other DJI Products SupportedZ15, H3-2D, H3-3D, iOSD, 2.4G Data Link, S800 EVO, S900, S1000, S1000+, etc. |
Flight Performance | Hovering Accuracy(In GPS Mode)Vertical: ± 0.5m Horizontal: ± 1.5m Maximum Wind Resistance< 8m/s (17.9mph/28.8km/h) Max Yaw Angular Velocity150 deg/s Max Tilt Angle35° Ascent/Descent±6m/s |
Electrical & Mechanical | Power ConsumptionMAX 5W (Typical Value: 0.3A@12.5V) Built-In FunctionsBuilt-in Receiver Multiple Control Modes 2-axis Gimbal Supported Low Voltage Protection PC & Bluetooth Ground Station External Receiver Supported Intelligent Orientation Control Sound Alarm 4 Configurable Output Total WeightTotal Weight: <= 224g(overall) DimensionsFlight Controller: 54mm x 39mm x 14.9mm IMU: 41.3mm x 30.5mm x 26.3mm GPS-Compass Pro: 62mm (diameter) x 14.3mm LED-BTU-I: 30mm x 30mm x 7.9mm PMU: 39.5mm x 27.6mm x 9.8mm |
Triple Modular RedundancyPrecision Controls with Fault-ToleranceCompatible with D-RTK GNSS, Smart ESCs, Intelligent Batteries, and Lightbridge 2DJI SDK CompatibilityPrecise Configuration with DJI Assistant 2
DJI DropSafe para6iuto sistema sumažina pavojų ir žalą kritiniu atveju. Iššauna parašiutą greičiau nei per pusę sekundės, efektyvus jau nuo 6 metrų. Sveria vos 550g ir yra daugkartinio naudojimo.
Profesionalus HD transliavimas per 3G-SDI ir mini-HDMI. Realaus laiko 1080p video perdavimas. Komplektacijoje Remote Controller valdymo pultas su integruotu siųstuvu. Vienu metu gali transliuoti du kanalus.
